Category:Automatic soldering machine
Application scope:
Communication industry: Apple product data cable HDMI、RJ45、FPC、 High frequency head and other products are suitable for soldering this equipment;
Optoelectronic industry: LED displays, LED strips, LED rectifiers, LED ball lights, LED beads and other products are suitable for soldering this equipment;
Home appliance industry: Products such as air conditioning remote controllers, air conditioning control boards, computer speakers, and TV switch connectors are suitable for soldering this equipment;
In the automotive industry, products such as ignition switches, fuel sensors, navigation systems, and motorcycle flashlights are suitable for soldering this equipment;
Toy industry: Toy handle connectors, circuit boards, and other products are suitable for soldering this equipment.

Automatic soldering machine - parameters

Overall dimensions		L815×W600×H880（mm)
work schedule	X-axis	300mm
	Y-axis	250mm
	Z-axis	80mm
	R-axis	±360°
Axial speed		0-500mm/s
Motion accuracy	XYZ axis	±0.01mm
	R-axis	±0.02°
temperature control		80℃－600℃
Temperature control accuracy		± 2 ℃ (no air flow, no load)
Tin delivery speed		０－50mm/s
Applicable tin wire diameter		0.5/0.6/0.8/1.0/1.2mm
Workbench load		10㎏
Program storage		999 of them
control system		PLC PID
ambient temperature		0－40℃
relative humidity		20％－90％
atmospheric pressure		0.4Mpa
power supply		220V 50Hz
weight		About 300kg
